Anaplastic Thyroid Carcinoma Initially Presented with Abdominal Cutaneous Mass and Hyperthyroidism

Article information

Abstract

INTRODUCTION

Anaplastic thyroid carcinoma (ATC) is one of the most aggressive endocrine tumors and has a poor prognosis with a median survival of 4 to 12 months from the time of diagnosis [1,2]. Fortunately, it accounts for only 1 to 2% of all thyroid cancer [3]. The mean age at diagnosis is 55 to 65 years [1,2]. Systemic metastases occur in up to 75% of patients during their illness, most commonly in the lungs in up to 80% of cases, followed by bone in 6-15% and the brain in 5-13% [4]. Skin metastases from thyroid carcinoma are extremely rare and usually occur in the setting of disseminated neoplastic disease [5]. Furthermore, primary thyroid malignancies typically do not interfere with thyroid function and the presentation of ATC with hyperthyroidism is extremely rare. Several case reports on subjects with ATC and hyperthyroidism have been published [6-15]. Here, we describe a rare case that presented with abdominal cutaneous metastasis from ATC, concurrent with the development of hyperthyroidism.

CASE REPORT

A 63-year-old female was admitted to our hospital for the evaluation of a huge abdominal mass. One month earlier, when the patient first perceived the abdominal mass, it measured about 2 cm. Recently, a neck mass also increased rapidly in size, with accompanying dysphagia, shortness of breath, and hoarseness. She had no history of goiter. On physical examination, she had a resting tachycardia with a pulse rate of 100-110 per minute. The abdominal mass was about 15 cm in diameter (Fig. 1A). A huge, firm neck mass occupied both lobes of the thyroid, with palpable lymph nodes on the left (Fig. 1B). She also had a 3-cm skin nodule on her right thigh that was hard and non-tender (Fig. 1C). Computed tomography (CT) revealed huge thyroid (Fig. 2A) and periumbilical (Fig. 2B) masses, infiltrating adjacent tissues. The abdominal mass was based primarily in the subcutaneous fat layer. A pulmonary mass, suggestive of metastasis, was also detected by CT. There was no definite evidence of bone metastasis on a bone scan. The initial thyroid function tests were consistent with a hyperthyroid state: thyroid stimulating hormone (TSH) < 0.11 mU/L (normal range, 0.4 to 4.1); free T4 (fT4) 3.34 ng/dL (normal range, 0.70 to 1.80); thyroglobulin 171.8 ng/mL (normal range, 0 to 40); and thyroglobulin antibody 85 U/mL (normal range, 0 to 100 U/mL). Anti-thyroglobulin antibody, anti-thyroid peroxidase antibody, and serum calcitonin were all normal.

Figure 1

A periumbilical mass about 15 cm in diameter (A), thyroid mass (B), and another skin lesion on the right thigh (C) were detected at the initial physical examination.

Figure 2

Computed tomography revealed a huge thyroid mass (A) and a cutaneous mass in the umbilical area (B).

Fine needle aspiration of the thyroid mass revealed many large, pleomorphic, epithelioid cells forming loose clusters and was compatible with anaplastic carcinoma of the thyroid (Fig. 3A). The histological features of the excised periumbilical mass were similar to those in the thyroid and the lesion was diagnosed as metastatic ACT (Fig. 3B). Immunohistochemical staining of the abdominal wall mass was positive for cytokeratin-7 and negative for cytokeratin-20, thyroid transcription factor-1, and thyroglobulin.

Figure 3

(A) Fine needle aspiration of the thyroid mass. The tumor is present as loose clusters or single cells and is composed of epithelioid cells with pleomorphic nuclei (Papanicolaou, × 400). (B) Excisional biopsy specimen from the periumbilical area. The tumor is composed of pleomorphic, epithelioid, and spindle cells with frequent mitotic figures (H&E, × 400).

After the diagnosis of ATC was made, palliative radiotherapy to the neck area was initiated on the 15th day of hospitalization, to relieve local symptoms associated with the thyroid mass. Although this patient had asymptomatic hyperthyroidism, she was given propylthiouracil preemptively because of the possibility of radiotherapy-induced thyrotoxicosis. During radiotherapy, the thyroid function tests were repeated on the 24th day and the fT4 and TSH levels were 3.09 ng/dL and < 0.05 mU/L, respectively. However, she had no thyrotoxic symptoms except tachycardia. The dyspnea was improved after the completion of radiotherapy (35 Gy/14 fractions) and systemic chemotherapy (paclitaxel) was administered on the 36th day. However, the tumor had an aggressive course despite chemotherapy. The patient developed vocal cord paralysis with severe airway compromise and died of respiratory distress on her 63rd day of hospitalization.

DISCUSSION

Anaplastic thyroid carcinoma is one of the most lethal solid tumors in humans. It aggressively invades adjacent tissues and frequently metastasizes to distant organs via the bloodstream. Distant metastases of ATC are usually localized in the lung, bone, and brain [4]. Cutaneous metastasis of thyroid cancer is very rare. The frequency of skin metastasis varies with the histological type of thyroid cancer. Dahl et al. [5] reviewed the English literature from 1964 onwards and found 43 cases of thyroid carcinoma with skin metastases. They found that papillary carcinoma was the most common thyroid cancer to result in skin metastases, representing 41% of the cases, followed by follicular carcinoma at 28%, with anaplastic carcinoma and medullary carcinoma each constituting 15% of the cases. By contrast, Koller et al. [16] reported that follicular carcinoma has a greater preponderance for cutaneous metastases than papillary carcinoma. Common cutaneous metastatic sites for the thyroid carcinoma are the scalp and neck [17,18]. However, cutaneous metastasis from ATC as the initial presentation is extremely rare and abdominal wall metastasis of ATC has not been reported.

A clinical presentation with hyperthyroidism is also rare in ATC. Sekiguchi et al. [19] studied the biological characteristics and chemosensitivity profiles in four human anaplastic thyroid carcinoma cell lines and found that all of four cell lines lost their differentiated function and were unable to synthesize thyroid hormone. Consequently, primary thyroid cancers typically do not interfere with thyroid function. The proposed mechanism for thyrotoxicosis is invasion and destruction of the normal thyroid parenchyma by the tumor, resulting in an excessive release of pre-formed thyroid hormone into the circulation. As this clinical presentation is analogous to various forms of thyroiditis, Rosen et al. [20] called this condition 'malignant pseudothyroiditis'. Subsequently, a few case reports of ATC patients with symptomatic or asymptomatic hyperthyroidism have been published [6-15]. Although the thyroid function tests revealed overt hyperthyroidism, our patient had no definite symptoms or signs of thyrotoxicosis.

Survival after the diagnosis of ATC is extremely poor. Since more than half of ATC patients have metastatic disease at presentation, the importance of chemotherapy in the management of ATC cannot be understated. However, the outcomes of chemotherapy have been very disappointing. Although doxorubicin is the drug used most commonly, it has a response rate of less than 22% and plays limited roles in the treatment of ATC [21]. In one phase II clinical study, paclitaxel showed promising results and had a 53% response rate [22]. However, this potential role of paclitaxel needs to be evaluated further, and our patient did not benefit from paclitaxel chemotherapy.

In conclusion, this case demonstrates that an abdominal cutaneous metastatic mass and hyperthyroidism can occur as manifestations of ATC. To our knowledge, this is the first reported case of ATC initially presenting with cutaneous metastasis in the abdominal wall, concurrent with hyperthyroidism. Further efforts to improve the treatment results for ATC patients are needed.
