Lee and Suh: A Case of Infected Biloma due to Spontaneous Intrahepatic Biliary Rupture

Abstract

A "biloma" is a loculated collection of bile located outside of the biliary tree. It can be caused by traumatic, iatrogenic or spontaneous rupture of the biliary tree. Prior reports have documented an association of biloma with abdominal trauma, surgery and other primary causes, but spontaneous bile leakage has rarely been reported. A spontaneous infected biloma, without any underlying disease, is a very rare finding. We recently diagnosed a spontaneous infected biloma by abdominal computed tomography and sonographically guided percutaneous aspiration. The patient was successfully managed with percutaneous drainage and intravenous antibiotics. We report here a case of infected biloma caused by spontaneous rupture of the intrahepatic duct, and review the relevant medical literature.

INTRODUCTION

A biloma is a rare abnormal accumulation of intrahepatic or extrahepatic bile caused by traumatic or spontaneous rupture of the biliary tree1, 2). It is most commonly caused by surgery, percutaneous transhepatic cholangiography (PTC), percutaneous transhepatic biliary drainage (PTBD), and abdominal trauma11, 12). A spontaneous occurrence of a biloma is a very rare condition. We report here a patient who complained of chills, fever and right upper quadrant abdominal discomfort. The patient was diagnosed with a biloma due to a spontaneous intrahepatic biliary rupture.

CASE REPORT

A 78-year-old woman presented to the emergency room with her guardian, with acute fever and chills that developed the day before admission. She had severe marasmus and complaints of abdominal discomfort. There was no history of trauma or hepatobiliary disease. The patient was diagnosed with diabetes a few years previously, but this was not being treated. The history included a cerebral infarct six years prior to presentation. She denied alcohol use. The patient had a 30-pack year cigarette smoking history. The patient's father had a history of cerebral infarct and hypertension.
On admission to the emergency room, the vital signs were as follows: blood pressure 70/40 mmHg, heart rate 118/min, respiratory rate 30/min and temperature 40.3℃. The patient appeared to be in acute distress; she was lethargic, the sclerae were slightly yellow and the conjunctivae were pale. The thoracic auscultation revealed rhythmic heartbeats and clear respirations. The abdominal examination revealed slight tenderness in the right upper quadrant, but there was no palpable mass. The remainder of the examination was within normal limits. The laboratory studies were as follows: WBC 52,400/mm3, Hb 12.3 g/dL, platelets 90,000/mm3, AST 153 IU/L, ALT 135 IU/L, alkaline phosphatase 255 IU/L, total bilirubin 2.07 mg/dL, total protein 5.9 g/dL, albumin 3.0 g/dL, BUN/Cr 25/1.9 mg/dL, ESR 25 mm/hr, and CRP 20.4 mg/dL. The serum electrolyte levels were normal except for an elevated potassium 7.0 mmol/L. The AFP and amylase were in normal ranges. The PT (15.9 sec) and PTT (47.3 sec) were elevated. The ABGA data were as follows: pH 7.24, PaO271 mmHg, PaCO2 19 mmHg, HCO3 15.1 mmol/L and SaO2 90.0%. The hepatitis viral marker tests, including HBsAg, anti-HBs Ab and anti-HCV, were all negative.
Standard X-rays on the day of admission revealed lung infiltrates and no specific findings in the abdomen. The abdominal computed tomography (CT) revealed a 9.5×8.5 cm subcapsular cyst with a clear boundary in the left hepatic lobe and enlargement of the intrahepatic bile duct around the cyst. Although the left hepatic lobe had some atrophic findings, there were no significant signs of an enlarged bile duct or abnormal gallbladder (Figure 1).
On the day of admission after the computed tomography, the blood pressure was 70/40 mmHg and voluntary respirations decreased. The ABGA revealed a pH 7.05, PCO2 64.8 mmHg, PO2 73.3 mmHg, HCO3 17.9 mmol/L and SaO2 87.4%, which indicated hypoxemia. The patient was intubated and put on a respirator; she was treated with antibiotics and vasopressors. On the second day of admission, percutaneous drainage with an 8.5 Fr pigtail catheter, under the guidance of an abdominal ultrasound was performed for diagnosis and treatment. We removed 565 mL of fluid that was dark brown in color. For a diagnosis, biochemical tests were carried out on the bile, and these tests revealed a total bilirubin of 22.3 mg/dL and a direct bilirubin of 18.9 mg/dL. The leukocyte count was 4,560/mm3, and gram staining showed a gram negative bacillus. On the third day of admission, her vital signs were as follows: blood pressure 100/65 mmHg, heart rate 110/min and temperature 37.2℃. There was 200 mL of drained bile, the s-fibrinogen was 894 mg/dL (200-415), the D-dimer was 9,040 ng/mL (0-255), and the FDP was elevated up to 97 ug/mL (normal range: 0-5). On the eighth day of admission, the patient's mental status improved, the vital signs were stable and voluntary respirations recovered. The patient was taken off the respirator and extubated. E.coli was isolated from the bile and blood samples. On the thirteenth day of admission, pancreatico-biliary magnetic resonance imaging (MRI) revealed a biloma that was connected to the intrahepatic bile duct (Figure 2). On the sixteenth day of admission, the biloma that was connected to the intrahepatic duct and common bile duct was noted again via a tubogram performed with a catheter.
Over time, the amount of bile drainage decreased. On the twentieth day of admission, 64 mL of bile was drained, the leukocyte count was 340/mm3 and there were no signs of bacteria on culture or gram staining of the bile. The follow-up CT showed that the size of the cyst had decreased to 5.4×4.6 cm and the density around the cyst had increased. The amount of drainage did not decrease afterward, and the connection between the biloma and the bile duct was still noted. On the 25th day of admission, the drainage tube was blocked and follow-up of the bilirubin in blood and the size of the biloma were assessed. On the 29th day of admission, follow-up CT showed a marked decrease in the size of the cyst (Figure 3), and the serum bilirubin was normal (0.22 mg/dL). On the 34th day of admission, the drainage tube was removed after evaluating the size and connection of the biloma via a catheter tubogram (Figure 4). The patient has been carefully monitored since discharge.

DISCUSSION

Gould and Patel reported the first case of a blioma in 19791). They reported a case with extrahepatic bile leakage after trauma to the upper right quadrant of the abdomen; the bile did not cause peritonitis, but it accumulated in an encapsulated form. This concept was later applied to all cases with biliary tract lacerations caused by bile leaks that formed a capsule inside or outside of the liver1). The mechanism of encapsulation is explained by a large amount of bile leaking at a fast pace that causes biliary peritonitis, or a small amount of bile leaking at a slow pace that causes mild inflammation. This leaked fluid is simultaneously trapped by the greater omentum and mesentery, where it becomes encapsulated2). Although the amount of bile leaked may be minor, the occurrence of an inflammatory reaction contributes to the appearance of a growth in size of the biloma3).
As diagnostic techniques continue to develop, more cases of biloma are being reported, but cases of spontaneous biloma and biloma accompanied by other diseases have rarely been reported to date. From 1979 to 1997, 25 cases of spontaneous biloma were analyzed by Fujiwara; the underlying causes included choledocholithiasis (16 cases), cholangiocarcinoma (2 cases), acute cholecystitis (1 case), liver infarction (1 case), hepatic abscess (1 case), nephrotic syndrome (1 case), obstructive jaundice (1 case), sickle cell anemia (1 case), and tuberculosis (1 case)4). In Korea, there have been two cases of choledocholithiasis accompanied by a biloma, and they were treated by nonsurgical methods5, 6). There is one report of a case of biloma after trauma7), and 1 case of a biloma after endoscopic retrograde cholangiopancreatography (ERCP)8). One of the patients with a choledocholithiasis who suffered a nontraumatic intrahepatic rupture of the bile duct, had a surgical repair9). The causes of biloma include trauma to the liver, which is the most common cause, abdominal surgery, endoscopic surgery and percutaneous catheter drainage10-13). Currently, the term biloma is generally used to describe intrahepatic or intraperitoneal focal biliary stasis14).
The clinical symptoms of a biloma are nonspecific, and they can range from no symptoms to abdominal pain and distention, jaundice and fever; leukocytosis can also be present15). In the case reported here there was no history of trauma, hepatobiliary tract examination or treatment. There were complaints of sudden chills, fever, upper abdominal discomfort and sensations of abdominal distention. Physical examinations showed tenderness in the upper right area of the abdomen, slight jaundice, hypotension, leukocytosis and fever over 40℃. The size and location of the biloma are determined by the cause of the rupture of the bile duct, the location and speed of bile leakage and the rate the bile is reabsorbed by the peritoneum2). Fujiwara reported that the locations for bile leakage included the left hepatobiliary duct (8 cases), the gallbladder (5 cases), the right hepatobiliary tract (2 cases), the common bile duct (1 case), and unknown (9 cases); the locations where the bilomas formed were the left lobe (11 cases), the right lobe (10 cases), and the upper abdomen (4 cases). Vazquez analyzed 21 cases of biloma and found that 16 cases occurred in the upper abdominal area near the liver and five in the left upper abdominal area4).
The diagnosis of a biloma can be assisted by surgery, a history of trauma with abdominal ultrasonography, abdominal CT and MRI. A definite diagnosis can be made by a 99mTc-DISIDA scan, percutaneous aspiration or by ERCP1, 2). Abdominal ultrasonography shows a mass of low echogenicity with a clear border in the liver, and the follow up tests show changes in size16). The abdominal CT will give a more accurate view of the location of the biloma and show its relationship to the surrounding organs. A standard CT view will show a low-density mass in the liver at a CT number lower than 20. Ultrasonography and abdominal CT are sometimes unable to differentiate bilomas from seromas, lymphoceles and angiomas. MRIs or hepatobiliary scans can be useful when continuous bile leakage is present, but they are not diagnostic when continuous leakage is not present7, 17). Radiological image-guided aspiration tests, when testing for bilirubin, can be diagnostic18). When the aspirated substance is a clear yellow liquid, then microbiological tests must be done to rule out an infection. ERCP can be used to determine the location and severity of an active bile leak. However, the presence of small biliary cysts or bilomas, located in the lower areas of the liver that can be hidden by gastrointestinal shadows, can be difficult to diagnosis19).
We were able to identify a cystic lesion by abdominal CT; a tubogram and magnetic resonance cholangiopancreatography (MRCP) were used to confirm a bile leak from the common bile duct. The fluid obtained by the transabdominal ultrasonography assisted percutaneous cyst drainage containing 22.3 mg/dL of total bilirubin and 18.9 mg/dL of direct bilirubin; these findings confirmed the diagnosis of a biloma.
Treatment for bilomas that have a diameter of only a few centimeters is not always necessary; these lesions can be watched. However, most bilomas require treatment. In the past, surgery was the main approach to treatment. Currently, there are a much wider variety of options such as percutaneous catheter drainage, endoscopic sphincterotomy (EST), endoscopic nasobiliary drainage (ENBD) and endoscopic drainage4, 6, 15, 19, 20). Surgery is now performed only in cases with a persistent bile leak or for treatment of underlying disease.
In this case, a spontaneous biloma with bacterial infection was found after the patient presented in septic shock. Transabdominal ultrasonography assistedpercutaneous drainage was performed and the patient recovered. After percutaneous drainage was performed, the amount of bile excreted did not decrease to lower than 64 mL per day. As there was no difficulty in flow through the common bile duct, the biochemical tests performed after removal of the drainage catheter showed no increase in total bilirubin or any increase in the size of the biloma, thus demonstrating a rare case of recovery.

References

1. Gould L, Patel A. Ultrasound detection of extrahepatic encapsulated bile: "biloma". AJR Am J Roentgenol 1979. 132:1014–1015PMID : 108953.
crossref pmid
2. Vazquez JL, Thorsen MK, Dodds WJ, Quiroz FA, Martinez ML, Lawson TL, Stewart ET, Foley WD. Evaluation and treatment of intraabdominal bilomas. AJR Am J Roentgenol 1985. 144:933–938PMID : 3885693.
crossref pmid
3. Zegel HG, Kurtz AB, Perlmutter GS, Goldberg BB. Ultrasonic characteristics of bilomas. J Clin Ultrasound 1981. 9:21–24PMID : 6792226.
crossref pmid
4. Fujiwara H, Yamamoto M, Takahashi M, Ishida H, Ohashi O, Onoyama H, Takeyama Y, Kuroda Y. Spontaneous rupture of an intrahepatic bile duct with biloma treated by percutaneous drainage and endoscopic sphincterotomy. Am J Gastroenterol 1998. 93:2282–2284PMID : 9820416.
crossref pmid
5. Kim HM, Kim MH, Kang JH, Lee OJ, Kim YC, Choi JH. A case report of biloma associated with intrahepatic and common bile duct stones. Korean J Med 1994. 47:110–114.

6. Kim MY, Choi SH, Kim YS, Lee SK, Song GA, Cho M, Yang US, Moon HK. A case report of biloma associated with choledocholithiasis. Korean J Gastroenterol 1994. 26:206–209.

7. Han MS, Lee SK, Dong SH, Lee SM, Kim HJ, Kim BH, Chang YW, Lee JI, Chang R, Hong SW. A case of posttraumatic biloma. Korean J Gastrointest Endosc 1995. 15:783–787.

8. Kim ST, Park YH, Kong H, Kim JH, Jo NY, Lee JG, Kim HJ, Kim JS, Bak YT, Lee CH. A case of hepatic biloma following endoscopic retrograde cholangiography. Korean J Gastrointest Endosc 2001. 23:56–59.

9. Jun KH, Cho HM, Chin HM, Yang JM, Hwang SS, Chun CS. A nontraumatic rupture of intrahepatic bile duct and perihepatic biloma formation in a patient with choledocholithiasis. Korean J Hepatobiliary Pancreat Surg 2004. 8:46–49.

10. Colovic R, Perisic-Savic M. Retroperitoneal biloma secondary to operative common bile duct injury. HPB Surg 1991. 3:193–197PMID : 2043516.
crossref pmid pmc pdf
11. Vujic I, Brock JG. Biloma: aspiration for diagnosis and treatment. Gastrointest Radiol 1982. 7:251–254PMID : 7106490.
crossref pmid
12. Mueller PR, Ferrucci JT Jr, Simesone JF, Cronan JJ, Wittenberg J, Neff CC, van Sonnenberg E. Detection and range of biloma: special considerations. AJR Am J Roentgenol 1983. 140:715–720PMID : 6601377.
crossref pmid
13. Kuligowska E, Schlesinger A, Miller KB, Lee VW, Grosso D. Biloma: a new approach to the diagnosis and treatment. Gastrointest Radiol 1983. 8:237–243PMID : 6618090.
crossref pmid
14. Yamamoto M, Kawano T, Anoda T. Biloma. Kan Tan Sui 1990. 21:451–454.

15. Binmmoeller K, Katon RM, Shneidman R. Endoscopic management of postoperative biliary leaks: review of 77 cases and report of two cases with biloma formation. Am J Gastroenterol 1991. 86:227–231PMID : 1992640.
pmid
16. Ralls PW, Eto R, Quinn M, Boger D. Gray scale ultrasonography of a traumatic biliary cyst. J Trauma 1981. 21:176–177PMID : 7206013.
crossref pmid
17. Weissmann HS, Chun KJ, Frank M, Koenigsberg M, Milstein DM, Freeman LM. Demonstration of traumatic bile leakage with cholescintigraphy and ultrasonography. AJR Am J Roentgenol 1979. 133:843–847PMID : 115271.
crossref pmid
18. Middleton JP, Wolper JC. Hepatic biloma complicating sickle cell disease: a case report and review of the literature. Gastroenterology 1984. 86:743–744PMID : 6698374.
pmid
19. Hartle RJ, McGattity TJ, Conter RL. Treatment of a giant biloma and bile leak by ERCP stent placement. Am J Gastroenterol 1993. 88:2117–2118PMID : 8249987.
pmid
20. Matsumoto R. A case of spontaneous Biloma successfully treated by Endoscopic Sphincterotomy. Gastroenterol Endosc 2000. 42:185–191.

Figure 1
Initial postcontrast abdominal CT findings. A thin walled large cystic lesion is noted in left hepatic lobe, and adjacent mildly dilated both intrahepatic duct and atrophy of left hepatic lobe without definite common bile duct dilatation are also seen.
Figure 2
The MRCP findings reveal communication of the biloma cavity with the intrahepatic duct (arrows) and drainage of the bile into the extrahepatic duct (arrowheads).
Figure 3
The abdominal CT finding 4 weeks after percutaneous drainage of the biloma shows a markedly decreased biloma.
Figure 4
The tubogram shows a well-placed pigtail catheter in the left hepatic lobe and drainage of bile into extrahepatic duct.
